ANENG PN103 6000 Counts Digital Clamp Meter Multimeter 600A AC Current AC/DC Voltage Tester Hz Capacitance NCV Ohm Diode Testers
ANENG PN103 6000 Counts Digital Clamp Meter Multimeter 600A AC Current AC/DC Voltage Tester Hz Capacitance NCV Ohm Diode Testers
SPECIFICATIONS
Measuring Resistance Range: 600/6K/60K/600K/6M/60M +-(0.8%+3)
Measuring Capacitance Range: 10nF/100nF/1UF/10UF/100UF/1mF/60mF
Operating Temperature: (5-35) temperature
Measuring Inductance Range: 10Hz/100Hz/1kHz/20kHz +-(0.5%+5)
Brand Name: ANENG
Model Number: ANENG PN103
Display Type: Digital Only
Origin: Mainland China
DIY Supplies: ELECTRICAL
ANENG Model: PN103
Measuring Current Range: 60A/600A +-(2.5%+10)
Measuring Voltage Range: 600mV/6V/60V/600V +-(0.8%+5)
Choice: yes
• High Precision :The ANENG PN103 digital clamp meter offers high precision measurements, ensuring accurate readings every time.
• Wide Range of Testing :With the ability to test AC/DC voltage, current, capacitance, NCV, and ohms, this multimeter is a versatile tool for any electrician.
• Easy to Use :The digital-only display makes it easy to read and interpret the results, and the simple design ensures that even beginners can use it with ease.
• Large Count :With 6000 counts, this clamp meter provides precise readings and is perfect for complex electrical systems.
ANENG PN103 Digital Clamp Meter AC/DC Current Professional Multimeter 6000 Counts True RMS Tester Meters Voltmeter Auto Range
A.Feature:
1-1. This series of clamp meters can automatically recognize the measurement range of AC current from 0.2 to 600A.
1-2. Overload protection throughout the range.
1-3. Max. voltage between measurement terminal and ground:700V DC or 600V AC
1-4. Max.display value:6000 digit.
1-5. Overrange display: The highest position shows"OL";
1-6.Low voltage display:"Low voltage symbol"symbol appears;
1-7.Power: AAA 1.5V battery(notinclude);
B.Function:
Function |
Range |
Accuracy |
AC/DC Current |
60A/600A |
+-(2.5%+10) |
DC voltage |
600mV/6V/60V/600V |
+-(0.8%+5) |
AC voltage |
6V/60V/600V |
+-(1.0%+5) |
Resistance |
600Ω/6K Ω/60k Ω/600K Ω/6m Ω/60mΩ |
+-(0.8%+3) |
Capacitor |
10nF/100nF/1uF/10uF/100uF/1mF/60mF |
+-(2.5%+20) |
Temperature |
(0~250)℃ |
- |
Frequency |
10Hz/100Hz/1kHz/20kHz |
+-(1%+5) |
Diode:yes |
NCV:yes |
Line on/off:yes |
date:yes |
Auto:yes |
C.Package:
according to your choice
